The Complete vLLM Guide — From PagedAttention to Production Optimization

# KV Cache size calculation during Transformer inference
def kv_cache_size_gb(
    num_layers: int,
    num_heads: int,
    head_dim: int,
    seq_len: int,
    batch_size: int,
    dtype_bytes: int = 2  # float16
) -> float:
    """
    KV Cache memory = 2 * L * H * D * S * B * dtype
    (2 = one each for K and V)
    """
    total_bytes = 2 * num_layers * num_heads * head_dim * seq_len * batch_size * dtype_bytes
    return total_bytes / (1024**3)

# Llama 3 70B example
print(kv_cache_size_gb(
    num_layers=80,
    num_heads=64,  # GQA: 8 KV heads
    head_dim=128,
    seq_len=4096,
    batch_size=1
))
# → approximately 5.2GB per request!

# With batch_size=32?
# → approximately 166GB — not enough even with 2x A100 80GB!

Traditional KV Cache allocation (contiguous memory):

Request 1: [████████████░░░░░░░░]  actual 1024 tokens, 4096 reserved
Request 2: [██████░░░░░░░░░░░░░░]  actual 512 tokens, 4096 reserved
Request 3: [████████████████░░░░]  actual 3072 tokens, 4096 reserved

Total reserved: 4096 * 3 = 12,288 slots
Actually used: 4,608 slots
Waste ratio: 62.5%!

PagedAttention KV Cache management:

Logical Blocks:
Request 1: [B0] → [B1] → [B2] → [B3]

Physical Blocks (GPU memory):
┌────┬────┬────┬────┬────┬────┬────┬────┐
│ B0 │ B2 │ B5 │ B1 │ B3 │ B6 │ B4 │ B7 │
│ R1 │ R1 │ R2 │ R1 │ R1 │ R2 │ R2 │FREE│
└────┴────┴────┴────┴────┴────┴────┴────┘

Page Table:
Request 1: [0→0, 1→3, 2→1, 3→4]
Request 2: [0→2, 1→5, 2→6]

# PagedAttention core structure
class PagedAttentionManager:
    def __init__(self, num_blocks: int, block_size: int, num_heads: int, head_dim: int):
        self.block_size = block_size  # e.g., 16 tokens per block
        self.num_blocks = num_blocks

        # Physical block pool (pre-allocated on GPU memory)
        self.k_cache = torch.zeros(
            num_blocks, block_size, num_heads, head_dim,
            dtype=torch.float16, device='cuda'
        )
        self.v_cache = torch.zeros_like(self.k_cache)

        # Free list
        self.free_blocks = list(range(num_blocks))

    def allocate_block(self) -> int:
        """Allocate a single physical block"""
        if not self.free_blocks:
            raise MemoryError("No free blocks")
        return self.free_blocks.pop()

    def free_block(self, block_id: int):
        """Return a block"""
        self.free_blocks.append(block_id)

    def append_token(self, request_id: int, key: torch.Tensor, value: torch.Tensor):
        """Add token — allocate a new block when current block is full"""
        page_table = self.page_tables[request_id]
        last_block = page_table[-1]
        slot_in_block = self.token_counts[request_id] % self.block_size

        if slot_in_block == 0 and self.token_counts[request_id] > 0:
            # New block needed
            new_block = self.allocate_block()
            page_table.append(new_block)
            last_block = new_block

        self.k_cache[last_block, slot_in_block] = key
        self.v_cache[last_block, slot_in_block] = value
        self.token_counts[request_id] += 1

# When multiple requests share the same system prompt
# Save memory with Copy-on-Write

system_prompt = "You are a helpful assistant..."
# Share KV Cache blocks of the system prompt

# Request 1: system_prompt + "What is Python?"
# Request 2: system_prompt + "Explain Docker"
# Request 3: system_prompt + "How to use Git?"

# Shared blocks:
# [System Block 0] ← shared by 3 requests (ref_count=3)
# [System Block 1] ← shared by 3 requests (ref_count=3)
# [System Block 2] ← shared by 3 requests (ref_count=3)

# Individual blocks:
# [R1 Block 3] [R2 Block 3] [R3 Block 3] ← each unique

# Memory savings: no need to copy system prompt blocks 3 times!

# Traditional Static Batching
# Wait until all requests finish
def static_batching(requests):
    """
    R1: ████████████ (done)
    R2: ████████████████████ (done)
    R3: ████ (done, but waiting...)
                              ↑ New batch starts only here
    """
    max_len = max(r.output_len for r in requests)
    for step in range(max_len):
        # Already finished requests still occupy GPU
        outputs = model.forward(batch)
    return outputs


# vLLM's Continuous Batching
def continuous_batching(scheduler):
    """
    Step 1: [R1, R2, R3] → process all
    Step 2: [R1, R2, R3] → R3 done! → insert R4 in empty slot
    Step 3: [R1, R2, R4] → R1 done! → insert R5
    Step 4: [R5, R2, R4] → ...

    GPU utilization: ~95% (vs Static's ~50-60%)
    """
    while requests_exist():
        # Remove completed requests, add new ones
        batch = scheduler.schedule()

        # Separate Prefill and Decode processing
        prefill_batch = [r for r in batch if r.is_prefill]
        decode_batch = [r for r in batch if r.is_decode]

        if prefill_batch:
            model.forward(prefill_batch, mode="prefill")
        if decode_batch:
            model.forward(decode_batch, mode="decode")

# pip install
pip install vllm

# Requires CUDA 12.1+, PyTorch 2.4+
# GPU: Compute Capability 7.0+ (V100, A100, H100, L40S, etc.)

from vllm import LLM, SamplingParams

# Load model
llm = LLM(
    model="meta-llama/Llama-3.1-8B-Instruct",
    dtype="auto",
    max_model_len=8192,
    gpu_memory_utilization=0.9,
    tensor_parallel_size=1,
)

# Sampling parameters
sampling_params = SamplingParams(
    temperature=0.7,
    top_p=0.9,
    max_tokens=1024,
    repetition_penalty=1.1,
)

# Batch inference
prompts = [
    "Explain the lifecycle of a Kubernetes Pod.",
    "What are the differences between Docker and Podman?",
    "Tell me about Redis caching strategies.",
]

outputs = llm.generate(prompts, sampling_params)
for output in outputs:
    print(f"Prompt: {output.prompt[:50]}...")
    print(f"Generated: {output.outputs[0].text[:100]}...")
    print(f"Tokens/s: {len(output.outputs[0].token_ids) / output.metrics.finished_time:.1f}")
    print()

# Run vLLM server (OpenAI API compatible)
vllm serve meta-llama/Llama-3.1-8B-Instruct \
  --host 0.0.0.0 \
  --port 8000 \
  --max-model-len 8192 \
  --gpu-memory-utilization 0.9 \
  --tensor-parallel-size 2 \
  --enable-prefix-caching \
  --max-num-seqs 256

# API call (OpenAI SDK compatible)
curl http://localhost:8000/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{
    "model": "meta-llama/Llama-3.1-8B-Instruct",
    "messages": [
      {"role": "system", "content": "You are a helpful assistant."},
      {"role": "user", "content": "What is vLLM?"}
    ],
    "temperature": 0.7,
    "max_tokens": 512
  }'

# Python SDK
from openai import OpenAI

client = OpenAI(
    base_url="http://localhost:8000/v1",
    api_key="dummy"  # vLLM does not require authentication
)

response = client.chat.completions.create(
    model="meta-llama/Llama-3.1-8B-Instruct",
    messages=[
        {"role": "user", "content": "Hello!"}
    ],
    stream=True
)

for chunk in response:
    if chunk.choices[0].delta.content:
        print(chunk.choices[0].delta.content, end="")

# Distribute model across 4 GPUs
vllm serve meta-llama/Llama-3.1-70B-Instruct \
  --tensor-parallel-size 4 \
  --dtype bfloat16

# 8 GPUs: 4-way TP × 2-way PP
vllm serve meta-llama/Llama-3.1-405B-Instruct \
  --tensor-parallel-size 4 \
  --pipeline-parallel-size 2

# Default is 0.9 (90%), can be set more aggressively
--gpu-memory-utilization 0.95

# Check number of KV Cache blocks
# Log: "# GPU blocks: 12345, # CPU blocks: 0"

# Effective when many requests share the same system prompt
--enable-prefix-caching

# Use AWQ quantized model
vllm serve TheBloke/Llama-3.1-70B-AWQ \
  --quantization awq \
  --dtype auto

# GPTQ
vllm serve TheBloke/Llama-3.1-70B-GPTQ \
  --quantization gptq

# FP8 (optimal on H100)
vllm serve meta-llama/Llama-3.1-70B-Instruct \
  --quantization fp8

# Speculate with small model → verify with large model
vllm serve meta-llama/Llama-3.1-70B-Instruct \
  --speculative-model meta-llama/Llama-3.1-8B-Instruct \
  --num-speculative-tokens 5

# vLLM benchmark tool
python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-8B-Instruct &

# Benchmark with ShareGPT dataset
python benchmarks/benchmark_serving.py \
  --backend vllm \
  --model meta-llama/Llama-3.1-8B-Instruct \
  --dataset-name sharegpt \
  --num-prompts 1000 \
  --request-rate 10

Benchmark results example (A100 80GB, Llama-3.1-8B):

| Metric          | vLLM    | TGI     | Pure HF |
|-----------------|---------|---------|---------|
| Throughput      | 2,400   | 1,800   | 400     |
| (tokens/s)      |         |         |         |
| TTFT p50 (ms)   | 45      | 60      | 200     |
| TTFT p99 (ms)   | 120     | 180     | 500     |
| ITL p50 (ms)    | 8       | 10      | 25      |
| Max Batch Size  | 256     | 128     | 16      |
| Memory Util.    | 95%     | 85%     | 60%     |

apiVersion: apps/v1
kind: Deployment
metadata:
  name: vllm-server
spec:
  replicas: 1
  selector:
    matchLabels:
      app: vllm
  template:
    metadata:
      labels:
        app: vllm
    spec:
      containers:
        - name: vllm
          image: vllm/vllm-openai:latest
          command:
            - python3
            - -m
            - vllm.entrypoints.openai.api_server
            - --model=meta-llama/Llama-3.1-8B-Instruct
            - --tensor-parallel-size=1
            - --gpu-memory-utilization=0.9
            - --max-model-len=8192
            - --enable-prefix-caching
          ports:
            - containerPort: 8000
          resources:
            limits:
              nvidia.com/gpu: 1
              memory: 32Gi
            requests:
              nvidia.com/gpu: 1
              memory: 24Gi
          readinessProbe:
            httpGet:
              path: /health
              port: 8000
            initialDelaySeconds: 120
            periodSeconds: 10
          volumeMounts:
            - name: model-cache
              mountPath: /root/.cache/huggingface
      volumes:
        - name: model-cache
          persistentVolumeClaim:
            claimName: model-cache-pvc
---
apiVersion: v1
kind: Service
metadata:
  name: vllm-service
spec:
  selector:
    app: vllm
  ports:
    - port: 80
      targetPort: 8000
  type: ClusterIP
