SLO and Error Budget Execution Manual

# prometheus_rules/sli_recording_rules.yaml
groups:
  - name: sli_availability
    interval: 30s
    rules:
      # API server availability SLI
      # "Good request" = all responses except HTTP 5xx
      - record: sli:api_availability:ratio_rate5m
        expr: |
          sum(rate(http_requests_total{status!~"5.."}[5m])) by (service)
          /
          sum(rate(http_requests_total[5m])) by (service)

  - name: sli_latency
    interval: 30s
    rules:
      # Latency SLI
      # "Good request" = requests completed within 300ms
      - record: sli:api_latency:ratio_rate5m
        expr: |
          sum(rate(http_request_duration_seconds_bucket{le="0.3"}[5m])) by (service)
          /
          sum(rate(http_request_duration_seconds_count[5m])) by (service)

# Bad SLI definition examples

# 1. Using server-side health checks as SLI (unrelated to user experience)
bad_sli_1 = "health_check_success_rate"  # Server is alive but responses might be slow

# 2. Success rate including internal retries (differs from actual user perception)
bad_sli_2 = "requests_eventually_succeeded / requests_total"  # Includes retries

# 3. Average latency (p50 might be fine but p99 could be 10 seconds)
bad_sli_3 = "avg(request_duration)"  # Average hides tail latency

# Good SLI definitions
good_sli = {
    "availability": "Ratio of first responses received by users that are non-5xx",
    "latency": "Ratio of responses perceived by users within 300ms",
    "correctness": "Ratio where 3+ of top 5 search results are relevant",
}

def calculate_error_budget(slo_target: float, window_days: int = 30) -> dict:
    """Calculate error budget from SLO target"""
    total_minutes = window_days * 24 * 60
    error_budget_fraction = 1.0 - slo_target
    allowed_bad_minutes = total_minutes * error_budget_fraction

    # Request-based calculation (assuming 1 million requests per day)
    daily_requests = 1_000_000
    total_requests = daily_requests * window_days
    allowed_bad_requests = int(total_requests * error_budget_fraction)

    return {
        "slo_target": f"{slo_target * 100:.2f}%",
        "window_days": window_days,
        "error_budget_fraction": f"{error_budget_fraction * 100:.3f}%",
        "allowed_bad_minutes": round(allowed_bad_minutes, 1),
        "allowed_bad_minutes_per_day": round(allowed_bad_minutes / window_days, 2),
        "allowed_bad_requests_30d": allowed_bad_requests,
    }

# Error budget comparison by SLO
for target in [0.999, 0.995, 0.99, 0.9]:
    budget = calculate_error_budget(target)
    print(f"SLO {budget['slo_target']:>7s}: "
          f"Monthly {budget['allowed_bad_minutes']:>7.1f}min = "
          f"Daily {budget['allowed_bad_minutes_per_day']:>5.2f}min, "
          f"Monthly {budget['allowed_bad_requests_30d']:>8,} bad requests allowed")

SLO  99.90%: Monthly    43.2min = Daily  1.44min, Monthly   30,000 bad requests allowed
SLO  99.50%: Monthly   216.0min = Daily  7.20min, Monthly  150,000 bad requests allowed
SLO  99.00%: Monthly   432.0min = Daily 14.40min, Monthly  300,000 bad requests allowed
SLO  90.00%: Monthly 4,320.0min = Daily144.00min, Monthly 3,000,000 bad requests allowed

def explain_burn_rate():
    """Burn rate concept explanation"""
    # burn rate = 1: exhausts error budget over exactly 30 days
    # burn rate = 14: exhausts error budget in about 2.1 days
    # burn rate = 2: exhausts error budget in about 15 days

    examples = {
        "burn_rate_14": {
            "meaning": "Exhausting 30-day budget in 2.1 days",
            "use_case": "Acute incident. Detection needed within 5 minutes",
            "long_window": "1h",
            "short_window": "5m",
        },
        "burn_rate_6": {
            "meaning": "Exhausting 30-day budget in 5 days",
            "use_case": "Significant performance degradation. Detection within 30 minutes",
            "long_window": "6h",
            "short_window": "30m",
        },
        "burn_rate_2": {
            "meaning": "Exhausting 30-day budget in 15 days",
            "use_case": "Gradual quality degradation. Detection within hours",
            "long_window": "3d",
            "short_window": "6h",
        },
        "burn_rate_1": {
            "meaning": "Exhausting 30-day budget in exactly 30 days",
            "use_case": "Review in weekly meeting. No immediate alert needed",
            "long_window": "N/A",
            "short_window": "N/A",
        },
    }
    return examples

# prometheus_rules/slo_alerts.yaml
groups:
  - name: slo_burn_rate_alerts
    rules:
      # === Tier 1: Acute Incident Detection (Burn Rate 14, 1h/5m window) ===
      - alert: SLOBurnRateCritical
        # long window: burn rate 14 or higher over 1h
        # short window: confirm still high over 5m (false positive prevention)
        expr: |
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[1h])) by (service)
                 / sum(rate(http_requests_total[1h])) by (service))
          ) > (14 * (1 - 0.999))
          and
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[5m])) by (service)
                 / sum(rate(http_requests_total[5m])) by (service))
          ) > (14 * (1 - 0.999))
        for: 1m
        labels:
          severity: critical
          slo_window: '1h/5m'
          burn_rate: '14'
        annotations:
          summary: '{{ $labels.service }}: SLO burn rate critical (14x)'
          description: |
            Service {{ $labels.service }} is consuming error budget at 14x
            the SLO rate. The entire budget will be exhausted in approximately 2.1 days.
            Investigate immediately.
          runbook: 'https://wiki.internal/runbook/slo-critical'

      # === Tier 2: Significant Performance Degradation (Burn Rate 6, 6h/30m window) ===
      - alert: SLOBurnRateHigh
        expr: |
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[6h])) by (service)
                 / sum(rate(http_requests_total[6h])) by (service))
          ) > (6 * (1 - 0.999))
          and
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[30m])) by (service)
                 / sum(rate(http_requests_total[30m])) by (service))
          ) > (6 * (1 - 0.999))
        for: 5m
        labels:
          severity: warning
          slo_window: '6h/30m'
          burn_rate: '6'
        annotations:
          summary: '{{ $labels.service }}: SLO burn rate high (6x)'
          description: |
            Service {{ $labels.service }} is consuming error budget at 6x
            the SLO rate. The entire budget will be exhausted in approximately 5 days.

      # === Tier 3: Gradual Quality Degradation (Burn Rate 2, 3d/6h window) ===
      - alert: SLOBurnRateLow
        expr: |
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[3d])) by (service)
                 / sum(rate(http_requests_total[3d])) by (service))
          ) > (2 * (1 - 0.999))
          and
          (
            1 - (sum(rate(http_requests_total{status!~"5.."}[6h])) by (service)
                 / sum(rate(http_requests_total[6h])) by (service))
          ) > (2 * (1 - 0.999))
        for: 30m
        labels:
          severity: info
          slo_window: '3d/6h'
          burn_rate: '2'
        annotations:
          summary: '{{ $labels.service }}: SLO burn rate elevated (2x)'

[Single Window: 1h]
10:00 - 10:05  Incident occurs, error rate 50%
10:05 - 10:10  Incident resolved, error rate 0%
...
10:55 - 11:00  Error rate 0%

-> Average error rate over 1h window: approximately 4.2%
-> Exceeds burn rate 14 threshold (0.014) -> Alert fires

But the incident ended 55 minutes ago!
=> False positive. On-call engineer gets paged for an already resolved issue.

[Multi-Window: 1h + 5m]
Long window (1h): Error rate 4.2% -> Exceeds threshold (O)
Short window (5m): Error rate 0% -> Below threshold (X)
=> Both conditions are not met, so no alert fires. Correct decision.

# error_budget_policy.yaml
# This document is agreed upon and signed by engineering leadership, product team, and SRE team.

policy:
  version: '2.0'
  effective_date: '2026-01-15'
  review_cycle: 'quarterly'

  budget_thresholds:
    # Budget >= 50%: Normal operations
    green:
      remaining_budget: '>= 50%'
      actions:
        - 'Feature development to reliability work ratio: 8:2'
        - 'Maintain standard release process'
        - 'Monitor trends in weekly SLO review'

    # Budget 20-50%: Caution
    yellow:
      remaining_budget: '20% ~ 50%'
      actions:
        - 'Feature development to reliability work ratio: 5:5'
        - 'Additional load testing required before releases'
        - 'Add canary stage to all deployments (1% -> 10% -> 50% -> 100%)'
        - 'SLO review twice per week'

    # Budget < 20%: Danger
    red:
      remaining_budget: '< 20%'
      actions:
        - 'Freeze new feature releases'
        - 'All personnel focused on reliability improvement'
        - 'VP approval required for all changes'
        - 'Daily SLO review'
        - 'Write postmortems and track action items'

    # Budget exhausted: Emergency
    exhausted:
      remaining_budget: '<= 0%'
      actions:
        - 'Immediately halt all non-essential deployments'
        - 'Review rollback candidates from changes in the last 30 days'
        - 'Escalate to CTO/VP'
        - 'Daily status reports'
        - 'Maintain feature freeze until window reset'

  exceptions:
    - 'Security patches are deployed immediately regardless of budget status'
    - 'Legal compliance requirements are exempt'
    - 'Emergency fixes to prevent data loss are exempt'

  escalation:
    - level: 'L1 (On-call Engineer)'
      condition: 'Burn rate alert fires'
      response_time: '15 minutes'
    - level: 'L2 (Team Lead)'
      condition: 'Budget < 50%'
      response_time: '1 hour'
    - level: 'L3 (VP Engineering)'
      condition: 'Budget < 20% or exhausted'
      response_time: 'Same day'

import datetime
import requests
from dataclasses import dataclass

@dataclass
class ErrorBudgetReport:
    service: str
    slo_target: float
    window_days: int
    current_sli: float
    budget_remaining_pct: float
    budget_remaining_minutes: float
    estimated_exhaustion_date: str
    policy_status: str  # green, yellow, red, exhausted

def calculate_error_budget_status(
    prometheus_url: str,
    service: str,
    slo_target: float = 0.999,
    window_days: int = 30,
) -> ErrorBudgetReport:
    """Query current SLI from Prometheus and calculate error budget status"""

    # Query current SLI (30-day window)
    query = f'''
        sum(rate(http_requests_total{{service="{service}",status!~"5.."}}[{window_days}d]))
        /
        sum(rate(http_requests_total{{service="{service}"}}[{window_days}d]))
    '''
    resp = requests.get(
        f"{prometheus_url}/api/v1/query",
        params={"query": query},
    )
    result = resp.json()["data"]["result"]
    current_sli = float(result[0]["value"][1]) if result else 0.0

    # Calculate error budget
    total_budget = 1.0 - slo_target  # e.g., 0.001
    consumed = max(0.0, (1.0 - current_sli) - 0)  # actual error rate
    remaining = max(0.0, total_budget - consumed)
    remaining_pct = (remaining / total_budget) * 100 if total_budget > 0 else 0

    # Convert to time
    total_minutes = window_days * 24 * 60
    remaining_minutes = total_minutes * (remaining / total_budget) if total_budget > 0 else 0

    # Calculate estimated exhaustion date
    if consumed > 0 and remaining > 0:
        burn_rate = consumed / total_budget
        days_to_exhaustion = window_days * (remaining / total_budget) / burn_rate
        exhaustion_date = (
            datetime.date.today() + datetime.timedelta(days=days_to_exhaustion)
        ).isoformat()
    elif remaining <= 0:
        exhaustion_date = "EXHAUSTED"
    else:
        exhaustion_date = "N/A (no errors)"

    # Determine policy status
    if remaining_pct >= 50:
        status = "green"
    elif remaining_pct >= 20:
        status = "yellow"
    elif remaining_pct > 0:
        status = "red"
    else:
        status = "exhausted"

    return ErrorBudgetReport(
        service=service,
        slo_target=slo_target,
        window_days=window_days,
        current_sli=round(current_sli, 6),
        budget_remaining_pct=round(remaining_pct, 2),
        budget_remaining_minutes=round(remaining_minutes, 1),
        estimated_exhaustion_date=exhaustion_date,
        policy_status=status,
    )

import json
from slack_sdk import WebClient

def send_weekly_slo_report(
    slack_token: str,
    channel: str,
    services: list[str],
    prometheus_url: str,
):
    """Send weekly SLO report to a Slack channel"""
    client = WebClient(token=slack_token)
    reports = []

    for service in services:
        report = calculate_error_budget_status(prometheus_url, service)
        reports.append(report)

    # Status emoji mapping (for Slack)
    status_emoji = {
        "green": ":large_green_circle:",
        "yellow": ":large_yellow_circle:",
        "red": ":red_circle:",
        "exhausted": ":rotating_light:",
    }

    blocks = [
        {"type": "header", "text": {"type": "plain_text", "text": "Weekly SLO Report"}},
        {"type": "divider"},
    ]

    for r in sorted(reports, key=lambda x: x.budget_remaining_pct):
        emoji = status_emoji[r.policy_status]
        blocks.append({
            "type": "section",
            "text": {
                "type": "mrkdwn",
                "text": (
                    f"{emoji} *{r.service}*\n"
                    f"  SLO: {r.slo_target*100:.2f}% | "
                    f"Current SLI: {r.current_sli*100:.4f}%\n"
                    f"  Budget remaining: {r.budget_remaining_pct:.1f}% "
                    f"({r.budget_remaining_minutes:.0f} min)\n"
                    f"  Estimated exhaustion: {r.estimated_exhaustion_date}"
                ),
            },
        })

    client.chat_postMessage(channel=channel, blocks=blocks)

# .github/workflows/release-gate.yaml
name: SLO Release Gate
on:
  workflow_call:
    inputs:
      service:
        required: true
        type: string

jobs:
  check-error-budget:
    runs-on: ubuntu-latest
    steps:
      - name: Query error budget status
        id: budget
        run: |
          RESULT=$(curl -s "${{ secrets.PROMETHEUS_URL }}/api/v1/query" \
            --data-urlencode "query=slo:error_budget_remaining_pct{service=\"${{ inputs.service }}\"}" \
            | jq -r '.data.result[0].value[1]')
          echo "remaining_pct=$RESULT" >> $GITHUB_OUTPUT

      - name: Evaluate release gate
        run: |
          BUDGET="${{ steps.budget.outputs.remaining_pct }}"
          echo "Error budget remaining: ${BUDGET}%"

          if (( $(echo "$BUDGET < 20" | bc -l) )); then
            echo "::error::ERROR BUDGET CRITICAL (${BUDGET}%). Release blocked."
            echo "Error budget is below 20%. Complete reliability work first."
            exit 1
          elif (( $(echo "$BUDGET < 50" | bc -l) )); then
            echo "::warning::Error budget at ${BUDGET}%. Canary deployment required."
            echo "canary_required=true" >> $GITHUB_OUTPUT
          else
            echo "Error budget healthy at ${BUDGET}%. Proceeding."
          fi

      - name: Notify Slack on block
        if: failure()
        run: |
          curl -X POST "${{ secrets.SLACK_WEBHOOK }}" \
            -H 'Content-Type: application/json' \
            -d "{\"text\":\"Release blocked for ${{ inputs.service }}: error budget < 20%\"}"

## SLO Impact Analysis

### Affected SLO

- Service: payment-api
- SLO Target: 99.95% availability (30-day window)
- Pre-incident SLI: 99.97%
- Post-incident SLI: 99.93%

### Error Budget Consumption

- Incident duration: 23 minutes
- Error requests during incident: 12,847
- Budget consumed relative to total window: 28.5%
- Pre-incident budget remaining: 71.2%
- Post-incident budget remaining: 42.7%

### Policy Status Change

- Before incident: GREEN (71.2%)
- After incident: YELLOW (42.7%)
- Action: Add canary stage to releases for the next 2 weeks

### Business Impact

- Failed payment attempts: approximately 3,200
- Estimated revenue loss: approximately $48,000
- Increase in customer inquiries: 127

# How to check
curl -s http://prometheus:9090/api/v1/query \
  --data-urlencode 'query=http_requests_total{status=~"5.."}' | jq '.data.result | length'
# If 0, 5xx metrics are not being collected

# Fix: Check the status code label in the application's metrics middleware
