LLM Structured Output Practical Guide — JSON Mode, Tool Use, Pydantic Schema Validation

Introduction
Structured Output Comparison by Provider
Automating Schema Validation with Pydantic
- Basic Pattern
- Retry Pattern (Self-Healing)
Unifying Providers with LiteLLM
Using the Instructor Library
Building a Production Pipeline
- FastAPI + Structured Output
- Batch Processing Pipeline
Conclusion

Introduction

To programmatically process LLM outputs, structured formats (JSON, XML, etc.) are essential. Simply adding "respond in JSON" to a prompt is not enough — various issues arise such as schema mismatches, missing fields, and incorrect types.

In this article, we compare the Structured Output features of major LLM providers and cover how to use them reliably in production.

Structured Output Comparison by Provider

OpenAI: response_format + Structured Outputs

from openai import OpenAI
from pydantic import BaseModel
from typing import List, Optional

client = OpenAI()

# Method 1: JSON Mode (basic)
response = client.chat.completions.create(
    model="gpt-4o-2024-08-06",
    messages=[
        {"role": "system", "content": "Return your response as JSON."},
        {"role": "user", "content": "Recommend 3 famous restaurants in Seoul"}
    ],
    response_format={"type": "json_object"}
)
# JSON is guaranteed, but schema is not

# Method 2: Structured Outputs (schema guaranteed)
class Restaurant(BaseModel):
    name: str
    cuisine: str
    price_range: str
    rating: float
    address: str

class RestaurantList(BaseModel):
    restaurants: List[Restaurant]
    total_count: int

response = client.beta.chat.completions.parse(
    model="gpt-4o-2024-08-06",
    messages=[
        {"role": "system", "content": "Recommend famous restaurants in Seoul."},
        {"role": "user", "content": "3 Korean cuisine restaurants"}
    ],
    response_format=RestaurantList
)

result = response.choices[0].message.parsed
print(result.restaurants[0].name)  # Type-safe!

Anthropic: Structured Output via Tool Use

import anthropic
from typing import List

client = anthropic.Anthropic()

# Anthropic uses Tool Use for Structured Output
response = client.messages.create(
    model="claude-sonnet-4-20250514",
    max_tokens=1024,
    tools=[
        {
            "name": "extract_restaurants",
            "description": "Extract restaurant information in a structured format",
            "input_schema": {
                "type": "object",
                "properties": {
                    "restaurants": {
                        "type": "array",
                        "items": {
                            "type": "object",
                            "properties": {
                                "name": {"type": "string"},
                                "cuisine": {"type": "string"},
                                "price_range": {
                                    "type": "string",
                                    "enum": ["$", "$$", "$$$", "$$$$"]
                                },
                                "rating": {"type": "number"},
                                "address": {"type": "string"}
                            },
                            "required": ["name", "cuisine", "price_range"]
                        }
                    },
                    "total_count": {"type": "integer"}
                },
                "required": ["restaurants", "total_count"]
            }
        }
    ],
    tool_choice={"type": "tool", "name": "extract_restaurants"},
    messages=[
        {"role": "user", "content": "Recommend 3 Korean restaurants in Seoul"}
    ]
)

# Extract structured data from Tool Use result
tool_use = next(
    block for block in response.content
    if block.type == "tool_use"
)
restaurants = tool_use.input["restaurants"]

Google Gemini: responseSchema

import google.generativeai as genai

genai.configure(api_key="YOUR_API_KEY")

model = genai.GenerativeModel(
    "gemini-2.0-flash",
    generation_config=genai.GenerationConfig(
        response_mime_type="application/json",
        response_schema={
            "type": "object",
            "properties": {
                "restaurants": {
                    "type": "array",
                    "items": {
                        "type": "object",
                        "properties": {
                            "name": {"type": "string"},
                            "cuisine": {"type": "string"},
                            "rating": {"type": "number"}
                        }
                    }
                }
            }
        }
    )
)

response = model.generate_content("3 Korean restaurants in Seoul")
import json
data = json.loads(response.text)

Automating Schema Validation with Pydantic

Basic Pattern

from pydantic import BaseModel, Field, validator
from typing import List, Optional, Literal
from enum import Enum
import json

class PriceRange(str, Enum):
    CHEAP = "$"
    MODERATE = "$$"
    EXPENSIVE = "$$$"
    VERY_EXPENSIVE = "$$$$"

class Restaurant(BaseModel):
    name: str = Field(..., min_length=1, max_length=100)
    cuisine: str = Field(..., description="Type of cuisine")
    price_range: PriceRange
    rating: float = Field(..., ge=0.0, le=5.0)
    address: Optional[str] = None
    tags: List[str] = Field(default_factory=list, max_length=10)

    @validator('rating')
    def round_rating(cls, v):
        return round(v, 1)

class RestaurantResponse(BaseModel):
    restaurants: List[Restaurant] = Field(..., min_length=1, max_length=20)
    query: str
    total_count: int

# Parse + validate LLM response
def parse_llm_response(raw_json: str) -> RestaurantResponse:
    """Parse LLM response and validate with Pydantic"""
    try:
        data = json.loads(raw_json)
        return RestaurantResponse(**data)
    except json.JSONDecodeError as e:
        raise ValueError(f"Invalid JSON: {e}")
    except Exception as e:
        raise ValueError(f"Schema validation failed: {e}")

Retry Pattern (Self-Healing)

from tenacity import retry, stop_after_attempt, retry_if_exception_type

class StructuredOutputParser:
    def __init__(self, client, model: str, schema: type[BaseModel]):
        self.client = client
        self.model = model
        self.schema = schema

    @retry(
        stop=stop_after_attempt(3),
        retry=retry_if_exception_type(ValueError)
    )
    def parse(self, prompt: str) -> BaseModel:
        """Retry with error message included on schema validation failure"""
        schema_json = self.schema.model_json_schema()

        messages = [
            {
                "role": "system",
                "content": f"Respond according to the following JSON schema:\n{json.dumps(schema_json, indent=2)}"
            },
            {"role": "user", "content": prompt}
        ]

        # Include error from previous attempt if available
        if hasattr(self, '_last_error'):
            messages.append({
                "role": "user",
                "content": f"An error occurred in the previous response: {self._last_error}\nPlease respond again with valid JSON."
            })

        response = self.client.chat.completions.create(
            model=self.model,
            messages=messages,
            response_format={"type": "json_object"}
        )

        raw = response.choices[0].message.content
        try:
            data = json.loads(raw)
            result = self.schema(**data)
            if hasattr(self, '_last_error'):
                del self._last_error
            return result
        except Exception as e:
            self._last_error = str(e)
            raise ValueError(str(e))

# Usage
parser = StructuredOutputParser(client, "gpt-4o", RestaurantResponse)
result = parser.parse("Recommend 3 Korean restaurants in Seoul")

Unifying Providers with LiteLLM

import litellm
from pydantic import BaseModel

class ExtractedInfo(BaseModel):
    summary: str
    key_points: list[str]
    sentiment: str
    confidence: float

# OpenAI
response = litellm.completion(
    model="gpt-4o",
    messages=[{"role": "user", "content": "Summarize the Kubernetes 1.35 release"}],
    response_format=ExtractedInfo
)

# Anthropic (automatically converts to Tool Use)
response = litellm.completion(
    model="claude-sonnet-4-20250514",
    messages=[{"role": "user", "content": "Summarize the Kubernetes 1.35 release"}],
    response_format=ExtractedInfo
)

# Gemini
response = litellm.completion(
    model="gemini/gemini-2.0-flash",
    messages=[{"role": "user", "content": "Summarize the Kubernetes 1.35 release"}],
    response_format=ExtractedInfo
)

# Same code works across all 3 providers!

Using the Instructor Library

# pip install instructor
import instructor
from openai import OpenAI
from pydantic import BaseModel
from typing import List

client = instructor.from_openai(OpenAI())

class Step(BaseModel):
    explanation: str
    output: str

class MathSolution(BaseModel):
    steps: List[Step]
    final_answer: str
    confidence: float

# Use Pydantic model directly as response_model
solution = client.chat.completions.create(
    model="gpt-4o",
    response_model=MathSolution,
    messages=[
        {"role": "user", "content": "Solve 2x + 5 = 15"}
    ],
    max_retries=3  # Automatic retries
)

print(solution.steps[0].explanation)
print(f"Answer: {solution.final_answer}")

# Anthropic is also supported the same way
import anthropic

anthropic_client = instructor.from_anthropic(anthropic.Anthropic())

solution = anthropic_client.messages.create(
    model="claude-sonnet-4-20250514",
    response_model=MathSolution,
    max_tokens=1024,
    messages=[
        {"role": "user", "content": "Solve 3x - 7 = 20"}
    ]
)

Building a Production Pipeline

FastAPI + Structured Output

from fastapi import FastAPI, HTTPException
from pydantic import BaseModel
from typing import List
import instructor
from openai import OpenAI

app = FastAPI()
client = instructor.from_openai(OpenAI())

class ProductReview(BaseModel):
    sentiment: str  # positive, negative, neutral
    score: float
    key_phrases: List[str]
    summary: str
    language: str

class ReviewRequest(BaseModel):
    text: str
    model: str = "gpt-4o-mini"

@app.post("/analyze", response_model=ProductReview)
async def analyze_review(request: ReviewRequest):
    try:
        result = client.chat.completions.create(
            model=request.model,
            response_model=ProductReview,
            messages=[
                {
                    "role": "system",
                    "content": "Analyze the product review."
                },
                {"role": "user", "content": request.text}
            ],
            max_retries=2
        )
        return result
    except Exception as e:
        raise HTTPException(status_code=500, detail=str(e))

Batch Processing Pipeline

import asyncio
from typing import List
from openai import AsyncOpenAI
import instructor

async_client = instructor.from_openai(AsyncOpenAI())

class ExtractedEntity(BaseModel):
    name: str
    entity_type: str
    confidence: float

class EntityExtractionResult(BaseModel):
    entities: List[ExtractedEntity]
    text_length: int

async def extract_entities(text: str) -> EntityExtractionResult:
    return await async_client.chat.completions.create(
        model="gpt-4o-mini",
        response_model=EntityExtractionResult,
        messages=[
            {"role": "system", "content": "Extract entities from the text."},
            {"role": "user", "content": text}
        ]
    )

async def batch_extract(texts: List[str], concurrency: int = 5):
    """Batch processing with concurrency limits"""
    semaphore = asyncio.Semaphore(concurrency)

    async def limited_extract(text):
        async with semaphore:
            return await extract_entities(text)

    tasks = [limited_extract(text) for text in texts]
    results = await asyncio.gather(*tasks, return_exceptions=True)

    successes = [r for r in results if not isinstance(r, Exception)]
    failures = [r for r in results if isinstance(r, Exception)]

    print(f"Successes: {len(successes)}, Failures: {len(failures)}")
    return successes

# Run
texts = ["A new AI startup in Seoul...", "Samsung Electronics semiconductor...", ...]
results = asyncio.run(batch_extract(texts))

Conclusion

Structured Output is a key technology for integrating LLMs into production systems:

OpenAI: 100% schema guarantee with response_format + Structured Outputs
Anthropic: An indirect approach via Tool Use, but reliable
Instructor/LiteLLM: Code reuse through provider unification
Pydantic: The standard for schema definition + validation
Retry Pattern: Stability through self-healing

Quiz (6 Questions)

Q1. What is the difference between OpenAI's JSON Mode and Structured Outputs? JSON Mode only guarantees valid JSON, while Structured Outputs also guarantees conformance to the specified schema

Q2. How does Anthropic implement Structured Output? It uses Tool Use (Function Calling) with input_schema to receive structured output

Q3. What does Pydantic's Field(ge=0.0, le=5.0) mean? A validation constraint that the value must be greater than or equal to 0.0 and less than or equal to 5.0

Q4. What is the max_retries feature in the instructor library? It automatically retries on schema validation failure to obtain the correct format

Q5. What is the role of asyncio.Semaphore in batch processing? It limits the number of concurrent API calls to prevent exceeding rate limits

Q6. What is the biggest benefit of using LiteLLM? The ability to switch between multiple providers like OpenAI, Anthropic, and Gemini with the same code
