MLflow Production Guide: Experiment Tracking, Model Registry, and Scalable MLOps Workflow

# docker-compose.production.yml
services:
  mlflow-server:
    image: ghcr.io/mlflow/mlflow:v2.20.0
    ports:
      - '5000:5000'
    environment:
      MLFLOW_BACKEND_STORE_URI: 'postgresql://mlflow:${DB_PASSWORD}@postgres:5432/mlflowdb'
      MLFLOW_DEFAULT_ARTIFACT_ROOT: 's3://mlflow-artifacts-prod/'
      AWS_ACCESS_KEY_ID: '${AWS_ACCESS_KEY_ID}'
      AWS_SECRET_ACCESS_KEY: '${AWS_SECRET_ACCESS_KEY}'
      AWS_DEFAULT_REGION: 'ap-northeast-1'
    command: >
      mlflow server
      --backend-store-uri postgresql://mlflow:${DB_PASSWORD}@postgres:5432/mlflowdb
      --default-artifact-root s3://mlflow-artifacts-prod/
      --host 0.0.0.0
      --port 5000
      --workers 4
      --app-name basic-auth
    depends_on:
      postgres:
        condition: service_healthy
    restart: unless-stopped

  postgres:
    image: postgres:16-alpine
    environment:
      POSTGRES_USER: mlflow
      POSTGRES_PASSWORD: '${DB_PASSWORD}'
      POSTGRES_DB: mlflowdb
    volumes:
      - pgdata:/var/lib/postgresql/data
    healthcheck:
      test: ['CMD-SHELL', 'pg_isready -U mlflow -d mlflowdb']
      interval: 10s
      timeout: 5s
      retries: 5
    restart: unless-stopped

  nginx:
    image: nginx:1.27-alpine
    ports:
      - '443:443'
      - '80:80'
    volumes:
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
      - ./certs:/etc/nginx/certs:ro
    depends_on:
      - mlflow-server
    restart: unless-stopped

volumes:
  pgdata:

# postgresql.conf adjustments for MLflow workloads
# Assuming 8GB RAM dedicated to PostgreSQL

shared_buffers = 2GB
effective_cache_size = 6GB
work_mem = 64MB
maintenance_work_mem = 512MB

# Write-heavy optimizations
wal_buffers = 64MB
checkpoint_completion_target = 0.9
max_wal_size = 4GB

# Connection pooling (use PgBouncer for 50+ concurrent training jobs)
max_connections = 200

import mlflow
from mlflow.tracking import MlflowClient

# Configure remote tracking server
mlflow.set_tracking_uri("https://mlflow.internal.company.com")

# Naming convention: team/project/experiment-type
# This enables filtering and access control at scale
EXPERIMENT_NAME = "recommendation-team/product-ranking/hyperparameter-search"

mlflow.set_experiment(EXPERIMENT_NAME)

client = MlflowClient()

def train_model(config: dict):
    """Production-grade experiment tracking with proper error handling."""
    with mlflow.start_run(
        run_name=f"xgb-{config['max_depth']}d-{config['learning_rate']}lr",
        tags={
            "team": "recommendation",
            "project": "product-ranking",
            "environment": "staging",
            "git_commit": config.get("git_sha", "unknown"),
            "data_version": config.get("data_version", "v1"),
        },
    ) as run:
        # Log all hyperparameters
        mlflow.log_params({
            "model_type": "xgboost",
            "max_depth": config["max_depth"],
            "learning_rate": config["learning_rate"],
            "n_estimators": config["n_estimators"],
            "subsample": config["subsample"],
            "colsample_bytree": config["colsample_bytree"],
            "eval_metric": "ndcg",
            "training_data_path": config["data_path"],
            "feature_count": config["feature_count"],
        })

        # Log dataset info as input
        dataset = mlflow.data.from_pandas(
            config["train_df"],
            source=config["data_path"],
            name="product_ranking_train",
        )
        mlflow.log_input(dataset, context="training")

        # Train model
        model = train_xgboost(config)

        # Log metrics at each evaluation point
        for epoch, metrics in enumerate(model.eval_history):
            mlflow.log_metrics({
                "train_ndcg": metrics["train_ndcg"],
                "val_ndcg": metrics["val_ndcg"],
                "train_loss": metrics["train_loss"],
                "val_loss": metrics["val_loss"],
            }, step=epoch)

        # Log final metrics
        final_metrics = evaluate_model(model, config["test_data"])
        mlflow.log_metrics({
            "test_ndcg": final_metrics["ndcg"],
            "test_precision_at_10": final_metrics["precision@10"],
            "test_recall_at_50": final_metrics["recall@50"],
            "test_mrr": final_metrics["mrr"],
            "inference_latency_p99_ms": final_metrics["latency_p99"],
        })

        # Log model with signature
        signature = mlflow.models.infer_signature(
            config["sample_input"],
            model.predict(config["sample_input"]),
        )
        mlflow.xgboost.log_model(
            model,
            artifact_path="model",
            signature=signature,
            registered_model_name="product-ranking-xgb",
        )

        # Log artifacts
        mlflow.log_artifact("feature_importance.png")
        mlflow.log_artifact("confusion_matrix.png")

        return run.info.run_id

import mlflow

def log_metrics_batched(metrics_buffer: list, batch_size: int = 100):
    """Batch metric logging to reduce HTTP overhead.

    Instead of logging every step individually, accumulate metrics
    and flush in batches. This reduces tracking server load by 50-100x
    for long training runs.
    """
    if len(metrics_buffer) >= batch_size:
        with mlflow.start_run(run_id=current_run_id):
            for step, metrics in metrics_buffer:
                mlflow.log_metrics(metrics, step=step)
        metrics_buffer.clear()


# Usage in training loop
metrics_buffer = []

for step in range(100000):
    loss = train_step()

    metrics_buffer.append((step, {
        "train_loss": loss,
        "learning_rate": scheduler.get_last_lr()[0],
    }))

    # Flush every 100 steps instead of every step
    log_metrics_batched(metrics_buffer, batch_size=100)

# Flush remaining metrics
log_metrics_batched(metrics_buffer, batch_size=1)

from mlflow.tracking import MlflowClient

client = MlflowClient()

# Register a new model version (happens automatically with log_model)
# or explicitly:
result = client.create_model_version(
    name="product-ranking-xgb",
    source="s3://mlflow-artifacts-prod/3/abc123/artifacts/model",
    run_id="abc123",
    description="XGBoost v2 with new user features, NDCG@10 improved 3.2%",
)
model_version = result.version

# Set aliases for deployment workflow
# Champion = currently serving production traffic
client.set_registered_model_alias(
    name="product-ranking-xgb",
    alias="champion",
    version=model_version,
)

# Challenger = candidate being validated in shadow mode
client.set_registered_model_alias(
    name="product-ranking-xgb",
    alias="challenger",
    version=model_version + 1,
)

# Load model by alias in serving code
champion_model = mlflow.pyfunc.load_model("models:/product-ranking-xgb@champion")
challenger_model = mlflow.pyfunc.load_model("models:/product-ranking-xgb@challenger")

# Add tags for additional metadata
client.set_model_version_tag(
    name="product-ranking-xgb",
    version=model_version,
    key="validation_status",
    value="passed",
)

client.set_model_version_tag(
    name="product-ranking-xgb",
    version=model_version,
    key="approved_by",
    value="ml-lead@company.com",
)

def promote_model(model_name: str, version: int, target_alias: str):
    """Promote a model version through the deployment lifecycle.

    Workflow: candidate -> challenger -> champion

    Each promotion requires passing validation gates:
    - candidate -> challenger: automated test suite passes
    - challenger -> champion: shadow mode metrics within tolerance
    """
    client = MlflowClient()

    # Get current model version info
    mv = client.get_model_version(name=model_name, version=str(version))

    # Validate promotion is allowed
    if target_alias == "challenger":
        # Must have passed automated validation
        tags = {t.key: t.value for t in mv.tags}
        if tags.get("validation_status") != "passed":
            raise ValueError(
                f"Model version {version} has not passed validation. "
                f"Current status: {tags.get('validation_status', 'unknown')}"
            )

    elif target_alias == "champion":
        # Must currently be challenger
        try:
            current_challenger = client.get_model_version_by_alias(
                name=model_name, alias="challenger"
            )
            if current_challenger.version != str(version):
                raise ValueError(
                    f"Version {version} is not the current challenger. "
                    f"Current challenger is version {current_challenger.version}"
                )
        except mlflow.exceptions.MlflowException:
            raise ValueError("No challenger alias set. Run shadow mode first.")

        # Archive old champion
        try:
            old_champion = client.get_model_version_by_alias(
                name=model_name, alias="champion"
            )
            client.set_model_version_tag(
                name=model_name,
                version=old_champion.version,
                key="archived_at",
                value=datetime.utcnow().isoformat(),
            )
            client.delete_registered_model_alias(
                name=model_name, alias="champion"
            )
        except mlflow.exceptions.MlflowException:
            pass  # No existing champion

    # Set the new alias
    client.set_registered_model_alias(
        name=model_name, alias=target_alias, version=version
    )

    # Tag the promotion event
    client.set_model_version_tag(
        name=model_name,
        version=str(version),
        key=f"promoted_to_{target_alias}_at",
        value=datetime.utcnow().isoformat(),
    )

    print(f"Model {model_name} v{version} promoted to {target_alias}")

# .github/workflows/ml-pipeline.yml
name: ML Training and Model Validation Pipeline

on:
  push:
    paths:
      - 'ml/**'
      - 'features/**'
    branches: [main]
  workflow_dispatch:
    inputs:
      experiment_name:
        description: 'MLflow experiment name'
        required: true
        default: 'recommendation-team/product-ranking/scheduled'

env:
  MLFLOW_TRACKING_URI: ${{ secrets.MLFLOW_TRACKING_URI }}
  MLFLOW_TRACKING_USERNAME: ${{ secrets.MLFLOW_TRACKING_USERNAME }}
  MLFLOW_TRACKING_PASSWORD: ${{ secrets.MLFLOW_TRACKING_PASSWORD }}
  AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
  AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}

jobs:
  train:
    runs-on: [self-hosted, gpu]
    outputs:
      run_id: ${{ steps.train.outputs.run_id }}
      model_version: ${{ steps.train.outputs.model_version }}
    steps:
      - uses: actions/checkout@v4

      - name: Set up Python
        uses: actions/setup-python@v5
        with:
          python-version: '3.11'
          cache: 'pip'

      - name: Install dependencies
        run: pip install -r requirements.txt

      - name: Run training
        id: train
        run: |
          python ml/train.py \
            --experiment-name "${{ github.event.inputs.experiment_name || 'recommendation-team/product-ranking/ci' }}" \
            --git-sha "${{ github.sha }}" \
            --data-version "$(date +%Y%m%d)"
          echo "run_id=$(cat /tmp/mlflow_run_id)" >> $GITHUB_OUTPUT
          echo "model_version=$(cat /tmp/mlflow_model_version)" >> $GITHUB_OUTPUT

  validate:
    needs: train
    runs-on: [self-hosted, gpu]
    steps:
      - uses: actions/checkout@v4

      - name: Install dependencies
        run: pip install -r requirements.txt

      - name: Run model validation
        run: |
          python ml/validate.py \
            --model-uri "models:/product-ranking-xgb/${{ needs.train.outputs.model_version }}" \
            --min-ndcg 0.45 \
            --max-latency-p99-ms 50 \
            --min-data-coverage 0.95

      - name: Set candidate alias
        if: success()
        run: |
          python -c "
          from mlflow.tracking import MlflowClient
          client = MlflowClient()
          client.set_registered_model_alias(
              'product-ranking-xgb', 'candidate',
              ${{ needs.train.outputs.model_version }}
          )
          client.set_model_version_tag(
              'product-ranking-xgb',
              '${{ needs.train.outputs.model_version }}',
              'validation_status', 'passed'
          )
          "

  promote-to-challenger:
    needs: [train, validate]
    runs-on: ubuntu-latest
    environment: staging
    steps:
      - uses: actions/checkout@v4

      - name: Install dependencies
        run: pip install mlflow

      - name: Promote to challenger
        run: |
          python ml/promote.py \
            --model-name "product-ranking-xgb" \
            --version "${{ needs.train.outputs.model_version }}" \
            --target-alias "challenger"

      - name: Deploy to shadow mode
        run: |
          kubectl set image deployment/ranking-shadow \
            model-server=ranking-server:v${{ needs.train.outputs.model_version }} \
            --namespace ml-staging

# .github/workflows/promote-champion.yml
name: Promote Challenger to Champion

on:
  workflow_dispatch:
    inputs:
      model_name:
        description: 'Registered model name'
        required: true
      version:
        description: 'Model version to promote'
        required: true

jobs:
  promote:
    runs-on: ubuntu-latest
    environment: production # Requires manual approval
    steps:
      - uses: actions/checkout@v4

      - name: Install dependencies
        run: pip install mlflow

      - name: Verify shadow mode metrics
        run: |
          python ml/verify_shadow_metrics.py \
            --model-name "${{ github.event.inputs.model_name }}" \
            --version "${{ github.event.inputs.version }}" \
            --min-hours-in-shadow 24 \
            --max-metric-degradation 0.02

      - name: Promote to champion
        run: |
          python ml/promote.py \
            --model-name "${{ github.event.inputs.model_name }}" \
            --version "${{ github.event.inputs.version }}" \
            --target-alias "champion"

      - name: Rolling deploy to production
        run: |
          kubectl set image deployment/ranking-prod \
            model-server=ranking-server:v${{ github.event.inputs.version }} \
            --namespace ml-production
          kubectl rollout status deployment/ranking-prod \
            --namespace ml-production --timeout=600s

"""
MLflow experiment namespace strategy for multi-team organizations.

Convention:
  {team}/{project}/{experiment-type}

Examples:
  recommendation-team/product-ranking/hyperparameter-search
  recommendation-team/product-ranking/feature-ablation
  search-team/query-understanding/weekly-retrain
  fraud-team/transaction-scoring/model-comparison

Model naming convention:
  {project}-{algorithm}

Examples:
  product-ranking-xgb
  query-understanding-bert
  transaction-scoring-lgbm
"""

import mlflow
from mlflow.tracking import MlflowClient
from dataclasses import dataclass


@dataclass
class ExperimentConfig:
    team: str
    project: str
    experiment_type: str

    @property
    def experiment_name(self) -> str:
        return f"{self.team}/{self.project}/{self.experiment_type}"

    @property
    def model_name_prefix(self) -> str:
        return self.project


def setup_experiment(config: ExperimentConfig) -> str:
    """Create or get experiment with proper tags for discoverability."""
    client = MlflowClient()

    experiment = client.get_experiment_by_name(config.experiment_name)

    if experiment is None:
        experiment_id = client.create_experiment(
            name=config.experiment_name,
            tags={
                "team": config.team,
                "project": config.project,
                "type": config.experiment_type,
                "owner": f"{config.team}-lead@company.com",
            },
        )
    else:
        experiment_id = experiment.experiment_id

    mlflow.set_experiment(experiment_id=experiment_id)
    return experiment_id

# Symptom: Training completes but model is not saved
# Error: botocore.exceptions.ClientError: AccessDenied

# Fix: Ensure the training job IAM role has BOTH:
# - s3:PutObject on the artifact bucket
# - s3:GetObject on the artifact bucket (for model loading)

# Verify permissions:
aws s3 cp test.txt s3://mlflow-artifacts-prod/test.txt
aws s3 ls s3://mlflow-artifacts-prod/

# Deploy PgBouncer between MLflow and PostgreSQL
# pgbouncer.ini
[databases]
mlflowdb = host=postgres port=5432 dbname=mlflowdb

[pgbouncer]
listen_port = 6432
listen_addr = 0.0.0.0
auth_type = md5
auth_file = /etc/pgbouncer/userlist.txt
pool_mode = transaction
max_client_conn = 500
default_pool_size = 30
min_pool_size = 10
reserve_pool_size = 5

import os

# Increase timeout for large model uploads (default is 120s)
os.environ["MLFLOW_HTTP_REQUEST_TIMEOUT"] = "600"

# For very large artifacts, use multipart upload
os.environ["MLFLOW_MULTIPART_UPLOAD_CHUNK_SIZE"] = "104857600"  # 100MB chunks

# BAD: Multiple workers logging to same run
# This causes step ordering issues and metric overwrites

# GOOD: Use child runs for distributed training
with mlflow.start_run(run_name="distributed-training") as parent_run:
    for worker_id in range(num_workers):
        with mlflow.start_run(
            run_name=f"worker-{worker_id}",
            nested=True,
        ) as child_run:
            # Each worker logs to its own child run
            train_worker(worker_id, child_run.info.run_id)

    # Aggregate metrics in parent run
    aggregate_and_log_metrics(parent_run.info.run_id)

# Enforce naming convention with a wrapper
def register_model_safe(model_uri: str, name: str, team: str):
    """Register model with team-prefix validation."""
    allowed_prefixes = {
        "recommendation": ["product-ranking", "user-embedding"],
        "search": ["query-understanding", "document-ranking"],
        "fraud": ["transaction-scoring", "account-risk"],
    }

    valid = any(
        name.startswith(prefix)
        for prefix in allowed_prefixes.get(team, [])
    )

    if not valid:
        raise ValueError(
            f"Team '{team}' cannot register model '{name}'. "
            f"Allowed prefixes: {allowed_prefixes.get(team, [])}"
        )

    return mlflow.register_model(model_uri, name)

from mlflow.tracking import MlflowClient
from datetime import datetime, timedelta

def cleanup_old_runs(
    experiment_name: str,
    max_age_days: int = 90,
    keep_top_n: int = 10,
    dry_run: bool = True,
):
    """Clean up old experiment runs while preserving top performers.

    WARNING: This permanently deletes runs and their artifacts.
    Always run with dry_run=True first.
    """
    client = MlflowClient()
    experiment = client.get_experiment_by_name(experiment_name)

    if experiment is None:
        print(f"Experiment '{experiment_name}' not found")
        return

    cutoff = datetime.now() - timedelta(days=max_age_days)
    cutoff_ms = int(cutoff.timestamp() * 1000)

    # Get all runs sorted by primary metric
    runs = client.search_runs(
        experiment_ids=[experiment.experiment_id],
        order_by=["metrics.val_ndcg DESC"],
    )

    # Protect top N runs regardless of age
    protected_run_ids = {r.info.run_id for r in runs[:keep_top_n]}

    deleted_count = 0
    for run in runs:
        if run.info.run_id in protected_run_ids:
            continue
        if run.info.end_time and run.info.end_time < cutoff_ms:
            if dry_run:
                print(f"Would delete run {run.info.run_id} "
                      f"(ended: {datetime.fromtimestamp(run.info.end_time/1000)})")
            else:
                client.delete_run(run.info.run_id)
            deleted_count += 1

    print(f"{'Would delete' if dry_run else 'Deleted'} {deleted_count} runs")
