OpenTelemetry 분산 트레이싱 실전 가이드: 계측·수집·분석 파이프라인 구축과 운영

# pip install opentelemetry-api opentelemetry-sdk opentelemetry-exporter-otlp

from opentelemetry import trace
from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from opentelemetry.sdk.resources import Resource
from opentelemetry.semconv.resource import ResourceAttributes

# 리소스 정의
resource = Resource.create({
    ResourceAttributes.SERVICE_NAME: "order-service",
    ResourceAttributes.SERVICE_VERSION: "1.2.0",
    ResourceAttributes.DEPLOYMENT_ENVIRONMENT: "production",
})

# TracerProvider 설정
provider = TracerProvider(resource=resource)
exporter = OTLPSpanExporter(endpoint="http://otel-collector:4317")
provider.add_span_processor(BatchSpanProcessor(exporter))
trace.set_tracer_provider(provider)

# Tracer 생성
tracer = trace.get_tracer("order-service", "1.2.0")


# 사용 예시: 주문 처리
def create_order(customer_id: str, items: list) -> dict:
    with tracer.start_as_current_span(
        "create_order",
        attributes={
            "customer.id": customer_id,
            "order.item_count": len(items),
        },
    ) as span:
        try:
            # 재고 확인
            with tracer.start_as_current_span("check_inventory") as inventory_span:
                available = check_inventory(items)
                inventory_span.set_attribute("inventory.all_available", available)

            if not available:
                span.set_status(trace.StatusCode.ERROR, "Inventory not available")
                raise ValueError("Some items are out of stock")

            # 결제 처리
            with tracer.start_as_current_span("process_payment") as payment_span:
                payment_result = process_payment(customer_id, items)
                payment_span.set_attribute("payment.transaction_id", payment_result["tx_id"])
                payment_span.add_event("payment_completed", {
                    "amount": payment_result["amount"],
                    "currency": "KRW",
                })

            # 주문 저장
            with tracer.start_as_current_span("save_order"):
                order = save_to_database(customer_id, items, payment_result)

            span.set_attribute("order.id", order["id"])
            return order

        except Exception as e:
            span.set_status(trace.StatusCode.ERROR, str(e))
            span.record_exception(e)
            raise

// npm install @opentelemetry/api @opentelemetry/sdk-node
// npm install @opentelemetry/exporter-trace-otlp-grpc
// npm install @opentelemetry/semantic-conventions

const { NodeSDK } = require('@opentelemetry/sdk-node')
const { OTLPTraceExporter } = require('@opentelemetry/exporter-trace-otlp-grpc')
const { Resource } = require('@opentelemetry/resources')
const { ATTR_SERVICE_NAME, ATTR_SERVICE_VERSION } = require('@opentelemetry/semantic-conventions')
const { trace, SpanStatusCode } = require('@opentelemetry/api')

// SDK 초기화
const sdk = new NodeSDK({
  resource: new Resource({
    [ATTR_SERVICE_NAME]: 'user-service',
    [ATTR_SERVICE_VERSION]: '2.1.0',
  }),
  traceExporter: new OTLPTraceExporter({
    url: 'http://otel-collector:4317',
  }),
})

sdk.start()

const tracer = trace.getTracer('user-service', '2.1.0')

// 사용 예시: 사용자 조회
async function getUser(userId) {
  return tracer.startActiveSpan('getUser', async (span) => {
    try {
      span.setAttribute('user.id', userId)

      // DB 조회
      const user = await tracer.startActiveSpan('db.query', async (dbSpan) => {
        dbSpan.setAttribute('db.system', 'postgresql')
        dbSpan.setAttribute('db.statement', 'SELECT * FROM users WHERE id = ?')
        const result = await db.query('SELECT * FROM users WHERE id = $1', [userId])
        dbSpan.setAttribute('db.row_count', result.rows.length)
        dbSpan.end()
        return result.rows[0]
      })

      if (!user) {
        span.setStatus({ code: SpanStatusCode.ERROR, message: 'User not found' })
        return null
      }

      // 캐시 업데이트
      await tracer.startActiveSpan('cache.set', async (cacheSpan) => {
        cacheSpan.setAttribute('cache.system', 'redis')
        cacheSpan.setAttribute('cache.key', `user:${userId}`)
        await redis.set(`user:${userId}`, JSON.stringify(user), 'EX', 3600)
        cacheSpan.end()
      })

      span.setStatus({ code: SpanStatusCode.OK })
      return user
    } catch (error) {
      span.setStatus({ code: SpanStatusCode.ERROR, message: error.message })
      span.recordException(error)
      throw error
    } finally {
      span.end()
    }
  })
}

package main

import (
    "context"
    "log"

    "go.opentelemetry.io/otel"
    "go.opentelemetry.io/otel/attribute"
    "go.opentelemetry.io/otel/codes"
    "go.opentelemetry.io/otel/exporters/otlp/otlptrace/otlptracegrpc"
    "go.opentelemetry.io/otel/sdk/resource"
    sdktrace "go.opentelemetry.io/otel/sdk/trace"
    semconv "go.opentelemetry.io/otel/semconv/v1.26.0"
    "go.opentelemetry.io/otel/trace"
)

func initTracer() (*sdktrace.TracerProvider, error) {
    exporter, err := otlptracegrpc.New(
        context.Background(),
        otlptracegrpc.WithEndpoint("otel-collector:4317"),
        otlptracegrpc.WithInsecure(),
    )
    if err != nil {
        return nil, err
    }

    res, err := resource.New(
        context.Background(),
        resource.WithAttributes(
            semconv.ServiceName("payment-service"),
            semconv.ServiceVersion("3.0.1"),
            semconv.DeploymentEnvironmentKey.String("production"),
        ),
    )
    if err != nil {
        return nil, err
    }

    tp := sdktrace.NewTracerProvider(
        sdktrace.WithBatcher(exporter),
        sdktrace.WithResource(res),
        sdktrace.WithSampler(sdktrace.ParentBased(sdktrace.TraceIDRatioBased(0.1))),
    )
    otel.SetTracerProvider(tp)
    return tp, nil
}

var tracer = otel.Tracer("payment-service")

func ProcessPayment(ctx context.Context, orderID string, amount float64) error {
    ctx, span := tracer.Start(ctx, "ProcessPayment",
        trace.WithAttributes(
            attribute.String("order.id", orderID),
            attribute.Float64("payment.amount", amount),
        ),
    )
    defer span.End()

    // 사기 탐지 확인
    ctx, fraudSpan := tracer.Start(ctx, "fraud_detection")
    isFraud, err := checkFraud(ctx, orderID, amount)
    if err != nil {
        fraudSpan.SetStatus(codes.Error, err.Error())
        fraudSpan.RecordError(err)
        fraudSpan.End()
        return err
    }
    fraudSpan.SetAttributes(attribute.Bool("fraud.detected", isFraud))
    fraudSpan.End()

    if isFraud {
        span.SetStatus(codes.Error, "Fraud detected")
        return fmt.Errorf("fraud detected for order %s", orderID)
    }

    // 결제 게이트웨이 호출
    ctx, gwSpan := tracer.Start(ctx, "payment_gateway_call")
    txID, err := callPaymentGateway(ctx, amount)
    if err != nil {
        gwSpan.SetStatus(codes.Error, err.Error())
        gwSpan.RecordError(err)
        gwSpan.End()
        return err
    }
    gwSpan.SetAttributes(attribute.String("payment.transaction_id", txID))
    gwSpan.End()

    span.SetStatus(codes.Ok, "Payment processed successfully")
    return nil
}

# 자동 계측 패키지 설치
pip install opentelemetry-distro opentelemetry-exporter-otlp
opentelemetry-bootstrap -a install

# 환경변수로 설정하여 실행
OTEL_SERVICE_NAME=order-service \
OTEL_TRACES_EXPORTER=otlp \
OTEL_EXPORTER_OTLP_ENDPOINT=http://otel-collector:4317 \
OTEL_PYTHON_LOG_CORRELATION=true \
opentelemetry-instrument python app.py

// tracing.js - 앱 시작 전에 로드
const { NodeSDK } = require('@opentelemetry/sdk-node')
const { getNodeAutoInstrumentations } = require('@opentelemetry/auto-instrumentations-node')
const { OTLPTraceExporter } = require('@opentelemetry/exporter-trace-otlp-grpc')

const sdk = new NodeSDK({
  traceExporter: new OTLPTraceExporter({
    url: 'http://otel-collector:4317',
  }),
  instrumentations: [
    getNodeAutoInstrumentations({
      '@opentelemetry/instrumentation-http': {
        ignoreIncomingPaths: ['/health', '/ready'],
      },
      '@opentelemetry/instrumentation-express': {
        enabled: true,
      },
      '@opentelemetry/instrumentation-pg': {
        enabled: true,
        enhancedDatabaseReporting: true,
      },
    }),
  ],
})

sdk.start()

process.on('SIGTERM', () => {
  sdk.shutdown().then(() => process.exit(0))
})

# 자동 계측으로 앱 실행
node --require ./tracing.js app.js

# otel-collector-config.yaml
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318

  # Jaeger 포맷도 수신 가능
  jaeger:
    protocols:
      thrift_http:
        endpoint: 0.0.0.0:14268

processors:
  # 배치 처리로 네트워크 효율성 향상
  batch:
    send_batch_size: 1024
    send_batch_max_size: 2048
    timeout: 5s

  # 메모리 사용량 제한
  memory_limiter:
    check_interval: 1s
    limit_mib: 512
    spike_limit_mib: 128

  # 리소스 속성 추가
  resource:
    attributes:
      - key: environment
        value: production
        action: upsert
      - key: cluster
        value: ap-northeast-2-prod
        action: upsert

  # 불필요한 속성 제거 (비용 절감)
  attributes:
    actions:
      - key: http.request.header.authorization
        action: delete
      - key: db.statement
        action: hash # SQL 쿼리 해싱 (보안)

  # 테일 기반 샘플링
  tail_sampling:
    decision_wait: 10s
    num_traces: 100000
    policies:
      - name: errors-policy
        type: status_code
        status_code:
          status_codes:
            - ERROR
      - name: slow-traces-policy
        type: latency
        latency:
          threshold_ms: 1000
      - name: probabilistic-policy
        type: probabilistic
        probabilistic:
          sampling_percentage: 10

exporters:
  # Grafana Tempo로 전송
  otlp/tempo:
    endpoint: tempo:4317
    tls:
      insecure: true

  # Jaeger로 전송
  otlp/jaeger:
    endpoint: jaeger:4317
    tls:
      insecure: true

  # 디버그 로그 출력
  debug:
    verbosity: detailed

service:
  pipelines:
    traces:
      receivers: [otlp, jaeger]
      processors: [memory_limiter, resource, attributes, tail_sampling, batch]
      exporters: [otlp/tempo, debug]

  telemetry:
    logs:
      level: info
    metrics:
      address: 0.0.0.0:8888

# Docker Compose로 Collector 배포
version: '3.8'
services:
  otel-collector:
    image: otel/opentelemetry-collector-contrib:0.96.0
    command: ['--config=/etc/otel/config.yaml']
    volumes:
      - ./otel-collector-config.yaml:/etc/otel/config.yaml
    ports:
      - '4317:4317' # OTLP gRPC
      - '4318:4318' # OTLP HTTP
      - '8888:8888' # Prometheus metrics
      - '8889:8889' # Prometheus exporter
      - '13133:13133' # Health check
    deploy:
      resources:
        limits:
          memory: 1G
          cpus: '1.0'

# Python SDK에서 head-based 샘플링 설정
from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.sampling import (
    TraceIdRatioBased,
    ParentBased,
    ALWAYS_ON,
    ALWAYS_OFF,
)

# 10% 확률 샘플링 (부모 스팬의 결정을 따름)
sampler = ParentBased(root=TraceIdRatioBased(0.1))

provider = TracerProvider(
    resource=resource,
    sampler=sampler,
)

# Collector에서 tail-based 샘플링 설정
processors:
  tail_sampling:
    decision_wait: 30s
    num_traces: 50000
    expected_new_traces_per_sec: 1000
    policies:
      # 에러가 있는 트레이스는 100% 수집
      - name: error-traces
        type: status_code
        status_code:
          status_codes: [ERROR]

      # 1초 이상 걸린 트레이스는 100% 수집
      - name: slow-traces
        type: latency
        latency:
          threshold_ms: 1000

      # 특정 서비스의 트레이스는 50% 수집
      - name: critical-service
        type: string_attribute
        string_attribute:
          key: service.name
          values: [payment-service, auth-service]
          enabled_regex_matching: false
        type: and
        and:
          and_sub_policy:
            - name: sample-critical
              type: probabilistic
              probabilistic:
                sampling_percentage: 50

      # 나머지는 5% 수집
      - name: default
        type: probabilistic
        probabilistic:
          sampling_percentage: 5

traceparent: 00-4bf92f3577b34da6a3ce929d0e0e4736-00f067aa0ba902b7-01
             ^^ ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^ ^^^^^^^^^^^^^^^^ ^^
             버전     trace-id (32 hex)          parent-id (16 hex) flags

# Python에서 W3C TraceContext 전파 설정
from opentelemetry import propagate
from opentelemetry.propagators.composite import CompositePropagator
from opentelemetry.propagators.textmap import DefaultTextMapPropagator

# W3C TraceContext (기본)
propagate.set_global_textmap(
    CompositePropagator([
        DefaultTextMapPropagator(),  # W3C TraceContext
    ])
)

# HTTP 요청에 컨텍스트 주입
import requests
from opentelemetry.propagate import inject

headers = {}
inject(headers)  # traceparent, tracestate 헤더 자동 추가
response = requests.get("http://downstream-service/api/data", headers=headers)

# B3 전파 설정 (Zipkin 호환이 필요한 경우)
from opentelemetry.propagators.b3 import B3MultiFormat

propagate.set_global_textmap(
    CompositePropagator([
        DefaultTextMapPropagator(),  # W3C
        B3MultiFormat(),             # B3 (Zipkin 호환)
    ])
)

# 트레이스 ID를 로그에 포함하여 상관관계 설정
import logging
from opentelemetry import trace

class TraceIdFilter(logging.Filter):
    def filter(self, record):
        span = trace.get_current_span()
        if span.is_recording():
            ctx = span.get_span_context()
            record.trace_id = format(ctx.trace_id, '032x')
            record.span_id = format(ctx.span_id, '016x')
        else:
            record.trace_id = '0' * 32
            record.span_id = '0' * 16
        return True

# 로그 설정
handler = logging.StreamHandler()
handler.setFormatter(logging.Formatter(
    '%(asctime)s %(levelname)s [trace_id=%(trace_id)s span_id=%(span_id)s] %(message)s'
))
handler.addFilter(TraceIdFilter())
logger = logging.getLogger(__name__)
logger.addHandler(handler)

# Kubernetes에서 Grafana Beyla 배포
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: beyla
spec:
  selector:
    matchLabels:
      app: beyla
  template:
    metadata:
      labels:
        app: beyla
    spec:
      hostPID: true
      containers:
        - name: beyla
          image: grafana/beyla:latest
          securityContext:
            privileged: true
          env:
            - name: BEYLA_OPEN_PORT
              value: '80,443,8080,3000'
            - name: OTEL_EXPORTER_OTLP_ENDPOINT
              value: 'http://otel-collector:4317'
            - name: BEYLA_SERVICE_NAMESPACE
              value: 'production'
          volumeMounts:
            - name: sys-kernel
              mountPath: /sys/kernel
      volumes:
        - name: sys-kernel
          hostPath:
            path: /sys/kernel

# 문제: 비동기 태스크에서 트레이스 컨텍스트가 사라짐
import asyncio
from opentelemetry import trace, context

async def process_order(order_id: str):
    with tracer.start_as_current_span("process_order") as span:
        # 잘못된 방식: 새 태스크에서 컨텍스트 전파 안 됨
        asyncio.create_task(send_notification(order_id))  # 컨텍스트 유실!

# 해결: 컨텍스트를 명시적으로 전달
async def process_order_fixed(order_id: str):
    with tracer.start_as_current_span("process_order") as span:
        ctx = context.get_current()
        asyncio.create_task(send_notification_with_context(order_id, ctx))

async def send_notification_with_context(order_id: str, ctx):
    token = context.attach(ctx)
    try:
        with tracer.start_as_current_span("send_notification"):
            # 알림 전송 로직
            pass
    finally:
        context.detach(token)

# 문제: head-based 샘플링을 0.1%로 설정하여 에러 트레이스도 대부분 누락
# SDK 설정
sampler: TraceIdRatioBased(0.001)  # 0.1% - 너무 낮음

# 해결: ParentBased + tail_sampling 조합 사용
# SDK에서는 전량 수집
sampler: ParentBased(root=ALWAYS_ON)

# Collector에서 tail-based 샘플링으로 에러/지연 보장
processors:
  tail_sampling:
    policies:
      - name: errors
        type: status_code
        status_code:
          status_codes: [ERROR]
      - name: latency
        type: latency
        latency:
          threshold_ms: 500
      - name: default
        type: probabilistic
        probabilistic:
          sampling_percentage: 1

# 문제: 트래픽 급증 시 Collector가 OOM으로 종료

# 해결: memory_limiter 프로세서 반드시 추가
processors:
  memory_limiter:
    check_interval: 1s
    limit_mib: 1024 # 최대 메모리 사용량
    spike_limit_mib: 256 # 스파이크 허용 범위
    limit_percentage: 80 # 전체 메모리의 80%

  batch:
    send_batch_size: 512 # 배치 크기 줄임
    timeout: 2s

service:
  pipelines:
    traces:
      # memory_limiter를 프로세서 체인 맨 앞에 배치
      processors: [memory_limiter, batch, tail_sampling]
