The Complete Guide to Helm Chart Authoring and Deployment Automation

mychart/
├── Chart.yaml          # Chart metadata
├── Chart.lock          # Dependency lock file
├── values.yaml         # Default configuration values
├── values-prod.yaml    # Production overrides
├── templates/          # Kubernetes manifest templates
│   ├── _helpers.tpl    # Common helper functions
│   ├── deployment.yaml
│   ├── service.yaml
│   ├── ingress.yaml
│   ├── hpa.yaml
│   ├── configmap.yaml
│   ├── secret.yaml
│   ├── serviceaccount.yaml
│   ├── NOTES.txt       # Post-install instructions
│   └── tests/
│       └── test-connection.yaml
├── charts/             # Dependency charts
└── .helmignore         # Files to exclude from packaging

apiVersion: v2
name: my-web-app
description: A production-ready web application
type: application
version: 1.2.0 # Chart version (SemVer)
appVersion: '3.1.0' # Application version
maintainers:
  - name: youngjukim
    email: fjvbn2003@gmail.com
dependencies:
  - name: postgresql
    version: '12.x.x'
    repository: 'https://charts.bitnami.com/bitnami'
    condition: postgresql.enabled
  - name: redis
    version: '17.x.x'
    repository: 'https://charts.bitnami.com/bitnami'
    condition: redis.enabled

# values.yaml - Default configuration
replicaCount: 2

image:
  repository: myregistry.io/my-web-app
  tag: '' # Uses Chart appVersion
  pullPolicy: IfNotPresent

service:
  type: ClusterIP
  port: 80
  targetPort: 8080

ingress:
  enabled: true
  className: nginx
  annotations:
    cert-manager.io/cluster-issuer: letsencrypt-prod
  hosts:
    - host: app.example.com
      paths:
        - path: /
          pathType: Prefix
  tls:
    - secretName: app-tls
      hosts:
        - app.example.com

resources:
  limits:
    cpu: 500m
    memory: 256Mi
  requests:
    cpu: 100m
    memory: 128Mi

autoscaling:
  enabled: false
  minReplicas: 2
  maxReplicas: 10
  targetCPUUtilizationPercentage: 80

postgresql:
  enabled: true
  auth:
    database: myapp
    username: appuser

redis:
  enabled: false

{{- define "mychart.name" -}}
{{- default .Chart.Name .Values.nameOverride | trunc 63 | trimSuffix "-" }}
{{- end }}

{{- define "mychart.fullname" -}}
{{- if .Values.fullnameOverride }}
{{- .Values.fullnameOverride | trunc 63 | trimSuffix "-" }}
{{- else }}
{{- $name := default .Chart.Name .Values.nameOverride }}
{{- if contains $name .Release.Name }}
{{- .Release.Name | trunc 63 | trimSuffix "-" }}
{{- else }}
{{- printf "%s-%s" .Release.Name $name | trunc 63 | trimSuffix "-" }}
{{- end }}
{{- end }}
{{- end }}

{{- define "mychart.labels" -}}
helm.sh/chart: {{ include "mychart.chart" . }}
app.kubernetes.io/name: {{ include "mychart.name" . }}
app.kubernetes.io/instance: {{ .Release.Name }}
app.kubernetes.io/version: {{ .Chart.AppVersion | quote }}
app.kubernetes.io/managed-by: {{ .Release.Service }}
{{- end }}

{{- define "mychart.selectorLabels" -}}
app.kubernetes.io/name: {{ include "mychart.name" . }}
app.kubernetes.io/instance: {{ .Release.Name }}
{{- end }}

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ include "mychart.fullname" . }}
  labels:
    {{- include "mychart.labels" . | nindent 4 }}
spec:
  {{- if not .Values.autoscaling.enabled }}
  replicas: {{ .Values.replicaCount }}
  {{- end }}
  selector:
    matchLabels:
      {{- include "mychart.selectorLabels" . | nindent 6 }}
  template:
    metadata:
      annotations:
        checksum/config: {{ include (print $.Template.BasePath "/configmap.yaml") . | sha256sum }}
      labels:
        {{- include "mychart.selectorLabels" . | nindent 8 }}
    spec:
      containers:
        - name: {{ .Chart.Name }}
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag | default .Chart.AppVersion }}"
          imagePullPolicy: {{ .Values.image.pullPolicy }}
          ports:
            - name: http
              containerPort: {{ .Values.service.targetPort }}
              protocol: TCP
          livenessProbe:
            httpGet:
              path: /healthz
              port: http
            initialDelaySeconds: 15
          readinessProbe:
            httpGet:
              path: /ready
              port: http
            initialDelaySeconds: 5
          resources:
            {{- toYaml .Values.resources | nindent 12 }}
          envFrom:
            - configMapRef:
                name: {{ include "mychart.fullname" . }}-config

# templates/pre-install-job.yaml
apiVersion: batch/v1
kind: Job
metadata:
  name: {{ include "mychart.fullname" . }}-db-migrate
  annotations:
    "helm.sh/hook": pre-install,pre-upgrade
    "helm.sh/hook-weight": "-5"
    "helm.sh/hook-delete-policy": before-hook-creation
spec:
  template:
    spec:
      restartPolicy: Never
      containers:
        - name: migrate
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag | default .Chart.AppVersion }}"
          command: ["python", "manage.py", "migrate"]
          envFrom:
            - secretRef:
                name: {{ include "mychart.fullname" . }}-db-secret
  backoffLimit: 3

# .github/workflows/deploy.yml
name: Deploy Helm Chart
on:
  push:
    branches: [main]

jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          aws-region: ap-northeast-2

      - name: Update kubeconfig
        run: aws eks update-kubeconfig --name my-cluster

      - name: Install Helm
        uses: azure/setup-helm@v3
        with:
          version: v3.14.0

      - name: Helm lint
        run: helm lint ./charts/my-web-app

      - name: Helm upgrade
        run: |
          helm upgrade --install my-app ./charts/my-web-app \
            --namespace production \
            --create-namespace \
            -f ./charts/my-web-app/values-prod.yaml \
            --set image.tag=${{ github.sha }} \
            --wait --timeout 5m

# Check rendered manifests
helm template my-release ./mychart -f values-prod.yaml

# Override specific values
helm template my-release ./mychart --set replicaCount=3

# Validate with kubeval
helm template my-release ./mychart | kubeval --strict

# templates/tests/test-connection.yaml
apiVersion: v1
kind: Pod
metadata:
  name: "{{ include "mychart.fullname" . }}-test"
  annotations:
    "helm.sh/hook": test
spec:
  containers:
    - name: curl
      image: curlimages/curl:8.5.0
      command: ['curl']
      args: ['{{ include "mychart.fullname" . }}:{{ .Values.service.port }}/healthz']
  restartPolicy: Never

# Run tests
helm test my-release -n production
