Event-Driven + Sagaアーキテクチャのトレードオフ

OrderService              InventoryService          PaymentService
    |                        |                        |
    |-- OrderCreated ------->|                        |
    |                        |-- InventoryReserved --->|
    |                        |                        |-- PaymentProcessed
    |<----------- OrderConfirmed ----------------------|

PaymentService: PaymentFailed
  --> InventoryService: InventoryReleased
    --> OrderService: OrderCancelled

SagaOrchestrator
    |-- (1) reserve_credit --> PaymentService
    |-- (2) reserve_inventory --> InventoryService
    |-- (3) create_shipment --> ShippingService
    |
    |  (3) 失敗時:
    |-- compensate (2) release_inventory
    |-- compensate (1) refund_credit

"""
Saga Orchestrator: 分散トランザクションの実行と補償を管理する。

各stepはexecute()とcompensate()を実装し、
orchestratorは順次実行後、失敗時に逆順で補償する。
"""
from dataclasses import dataclass, field
from enum import Enum
from typing import Optional
import logging
import uuid
import time

logger = logging.getLogger(__name__)


class SagaStatus(Enum):
    PENDING = "pending"
    RUNNING = "running"
    COMPLETED = "completed"
    COMPENSATING = "compensating"
    COMPENSATED = "compensated"
    FAILED = "failed"  # 補償自体が失敗した場合


class StepStatus(Enum):
    PENDING = "pending"
    EXECUTED = "executed"
    COMPENSATED = "compensated"
    COMPENSATION_FAILED = "compensation_failed"


@dataclass
class SagaStep:
    """Sagaの個別ステップ。

    execute()とcompensate()はサブクラスで実装する。
    idempotency_keyによりリトライの安全性を保証する。
    """
    name: str
    status: StepStatus = StepStatus.PENDING
    idempotency_key: str = ""
    executed_at: Optional[float] = None
    compensated_at: Optional[float] = None
    error: Optional[str] = None

    def __post_init__(self):
        if not self.idempotency_key:
            self.idempotency_key = str(uuid.uuid4())

    def execute(self, context: dict) -> dict:
        raise NotImplementedError

    def compensate(self, context: dict) -> None:
        raise NotImplementedError


@dataclass
class SagaExecution:
    """Saga実行記録。"""
    saga_id: str
    status: SagaStatus = SagaStatus.PENDING
    steps: list[SagaStep] = field(default_factory=list)
    context: dict = field(default_factory=dict)
    started_at: Optional[float] = None
    completed_at: Optional[float] = None
    error: Optional[str] = None


class SagaOrchestrator:
    """Saga実行を管理するorchestrator。

    実行フロー：
    1. 各stepを順次execute()
    2. いずれかのstepが失敗したら、既に実行されたstepを逆順でcompensate()
    3. 補償も失敗したらFAILED状態で記録しアラート送信
    """

    def __init__(self, steps: list[SagaStep], on_failure: Optional[callable] = None):
        self.steps = steps
        self.on_failure = on_failure  # 補償失敗時に呼び出すコールバック

    def run(self, initial_context: dict | None = None) -> SagaExecution:
        execution = SagaExecution(
            saga_id=str(uuid.uuid4()),
            steps=self.steps,
            context=initial_context or {},
            started_at=time.time(),
        )
        execution.status = SagaStatus.RUNNING
        completed_steps: list[SagaStep] = []

        logger.info(f"Saga {execution.saga_id} started with {len(self.steps)} steps")

        try:
            for step in self.steps:
                logger.info(f"Saga {execution.saga_id}: executing '{step.name}'")
                try:
                    result = step.execute(execution.context)
                    step.status = StepStatus.EXECUTED
                    step.executed_at = time.time()

                    # stepの結果をcontextにマージ
                    if isinstance(result, dict):
                        execution.context.update(result)

                    completed_steps.append(step)

                except Exception as e:
                    step.error = str(e)
                    logger.error(
                        f"Saga {execution.saga_id}: step '{step.name}' failed: {e}"
                    )
                    # 補償開始
                    self._compensate(execution, completed_steps)
                    return execution

            execution.status = SagaStatus.COMPLETED
            execution.completed_at = time.time()
            logger.info(f"Saga {execution.saga_id} completed successfully")

        except Exception as e:
            execution.status = SagaStatus.FAILED
            execution.error = str(e)
            logger.critical(f"Saga {execution.saga_id} unexpected error: {e}")

        return execution

    def _compensate(self, execution: SagaExecution, completed_steps: list[SagaStep]):
        """完了したstepを逆順で補償する。"""
        execution.status = SagaStatus.COMPENSATING
        compensation_failures = []

        for step in reversed(completed_steps):
            logger.info(
                f"Saga {execution.saga_id}: compensating '{step.name}'"
            )
            try:
                step.compensate(execution.context)
                step.status = StepStatus.COMPENSATED
                step.compensated_at = time.time()
            except Exception as e:
                step.status = StepStatus.COMPENSATION_FAILED
                step.error = f"Compensation failed: {e}"
                compensation_failures.append((step.name, str(e)))
                logger.critical(
                    f"Saga {execution.saga_id}: compensation of '{step.name}' FAILED: {e}"
                )

        if compensation_failures:
            execution.status = SagaStatus.FAILED
            execution.error = f"Compensation failures: {compensation_failures}"
            if self.on_failure:
                self.on_failure(execution, compensation_failures)
        else:
            execution.status = SagaStatus.COMPENSATED
            execution.completed_at = time.time()

class ReserveCreditStep(SagaStep):
    """決済サービスにクレジットを予約する。"""

    def __init__(self, payment_client):
        super().__init__(name="reserve_credit")
        self.payment_client = payment_client

    def execute(self, context: dict) -> dict:
        result = self.payment_client.reserve(
            customer_id=context["customer_id"],
            amount=context["order_total"],
            idempotency_key=self.idempotency_key,
        )
        return {"reservation_id": result.reservation_id}

    def compensate(self, context: dict) -> None:
        self.payment_client.release(
            reservation_id=context["reservation_id"],
            idempotency_key=f"{self.idempotency_key}_compensate",
        )


class ReserveInventoryStep(SagaStep):
    """在庫サービスに商品を予約する。"""

    def __init__(self, inventory_client):
        super().__init__(name="reserve_inventory")
        self.inventory_client = inventory_client

    def execute(self, context: dict) -> dict:
        result = self.inventory_client.reserve(
            items=context["order_items"],
            idempotency_key=self.idempotency_key,
        )
        return {"inventory_reservation_id": result.reservation_id}

    def compensate(self, context: dict) -> None:
        self.inventory_client.release(
            reservation_id=context["inventory_reservation_id"],
            idempotency_key=f"{self.idempotency_key}_compensate",
        )

{
  "$schema": "https://json-schema.org/draft/2020-12/schema",
  "$id": "https://events.example.com/order/created/v2",
  "title": "OrderCreated",
  "description": "注文が作成された時に発行されるイベント",
  "type": "object",
  "required": ["event_id", "event_type", "event_version", "timestamp", "data"],
  "properties": {
    "event_id": {
      "type": "string",
      "format": "uuid",
      "description": "イベント固有ID（idempotency keyとして使用）"
    },
    "event_type": {
      "type": "string",
      "const": "order.created"
    },
    "event_version": {
      "type": "integer",
      "const": 2,
      "description": "スキーマバージョン。互換性判断に使用"
    },
    "timestamp": {
      "type": "string",
      "format": "date-time"
    },
    "data": {
      "type": "object",
      "required": ["order_id", "customer_id", "items", "total_amount"],
      "properties": {
        "order_id": { "type": "string" },
        "customer_id": { "type": "string" },
        "items": {
          "type": "array",
          "items": {
            "type": "object",
            "required": ["sku", "quantity", "unit_price"],
            "properties": {
              "sku": { "type": "string" },
              "quantity": { "type": "integer", "minimum": 1 },
              "unit_price": { "type": "number", "minimum": 0 }
            }
          }
        },
        "total_amount": { "type": "number", "minimum": 0 },
        "currency": { "type": "string", "default": "KRW" },
        "shipping_address": {
          "type": "object",
          "description": "v2で追加されたフィールド。v1コンシューマーはこのフィールドを無視する。"
        }
      }
    }
  }
}

# 危険なパターン
1. DBに注文保存     -- 成功
2. Kafkaにイベント発行 -- 失敗（ネットワーク問題）
=> 注文は作成されたがイベントがないため、在庫も引かれず決済もされない

-- outboxテーブルスキーマ
CREATE TABLE outbox (
    id              UUID PRIMARY KEY DEFAULT gen_random_uuid(),
    aggregate_type  VARCHAR(100) NOT NULL,    -- 'Order', 'Payment' 等
    aggregate_id    VARCHAR(100) NOT NULL,    -- 注文ID、決済ID
    event_type      VARCHAR(200) NOT NULL,    -- 'order.created'
    event_version   INT NOT NULL DEFAULT 1,
    payload         JSONB NOT NULL,
    created_at      TIMESTAMPTZ NOT NULL DEFAULT NOW(),
    published_at    TIMESTAMPTZ,              -- NULLなら未発行
    retry_count     INT NOT NULL DEFAULT 0,
    max_retries     INT NOT NULL DEFAULT 5
);

-- 未発行イベント検索インデックス
CREATE INDEX idx_outbox_unpublished
    ON outbox (created_at)
    WHERE published_at IS NULL AND retry_count < max_retries;

-- 注文作成とイベントを1つのトランザクションで処理
BEGIN;
    INSERT INTO orders (id, customer_id, total, status)
    VALUES ('ord-123', 'cust-456', 50000, 'created');

    INSERT INTO outbox (aggregate_type, aggregate_id, event_type, payload)
    VALUES (
        'Order',
        'ord-123',
        'order.created',
        '{"order_id": "ord-123", "customer_id": "cust-456", "total": 50000}'::jsonb
    );
COMMIT;

"""
Outbox Publisher: outboxテーブルの未発行イベントをbrokerに配信する。

at-least-once配信を保証し、コンシューマー側で
idempotencyを処理する必要がある。
"""
import time
import json
import logging

logger = logging.getLogger(__name__)


class OutboxPublisher:
    def __init__(self, db_pool, kafka_producer, poll_interval_seconds: float = 1.0):
        self.db_pool = db_pool
        self.producer = kafka_producer
        self.poll_interval = poll_interval_seconds

    def run(self):
        """メインループ。未発行イベントを継続的にポーリングして発行する。"""
        logger.info("OutboxPublisher started")
        while True:
            try:
                published_count = self._poll_and_publish()
                if published_count == 0:
                    time.sleep(self.poll_interval)
            except Exception as e:
                logger.error(f"OutboxPublisher error: {e}")
                time.sleep(self.poll_interval * 5)

    def _poll_and_publish(self, batch_size: int = 100) -> int:
        """未発行イベントのバッチを検索し発行する。"""
        with self.db_pool.connection() as conn:
            with conn.cursor() as cur:
                cur.execute("""
                    SELECT id, aggregate_type, aggregate_id,
                           event_type, event_version, payload
                    FROM outbox
                    WHERE published_at IS NULL
                      AND retry_count < max_retries
                    ORDER BY created_at
                    LIMIT %s
                    FOR UPDATE SKIP LOCKED
                """, (batch_size,))

                rows = cur.fetchall()
                if not rows:
                    return 0

                published_ids = []
                failed_ids = []

                for row in rows:
                    event_id, agg_type, agg_id, evt_type, evt_ver, payload = row
                    topic = f"{agg_type.lower()}-events"

                    try:
                        self.producer.send(
                            topic=topic,
                            key=agg_id.encode(),
                            value=json.dumps({
                                "event_id": str(event_id),
                                "event_type": evt_type,
                                "event_version": evt_ver,
                                "data": payload,
                            }).encode(),
                        )
                        published_ids.append(event_id)
                    except Exception as e:
                        logger.warning(f"Failed to publish {event_id}: {e}")
                        failed_ids.append(event_id)

                # 成功したイベントをマーク
                if published_ids:
                    cur.execute("""
                        UPDATE outbox SET published_at = NOW()
                        WHERE id = ANY(%s)
                    """, (published_ids,))

                # 失敗したイベントのリトライカウントを増加
                if failed_ids:
                    cur.execute("""
                        UPDATE outbox SET retry_count = retry_count + 1
                        WHERE id = ANY(%s)
                    """, (failed_ids,))

                conn.commit()
                return len(published_ids)

class IdempotentEventHandler:
    """重複イベントを安全に処理するハンドラーラッパー。

    event_idをキーとして処理履歴を記録し、
    既に処理済みのイベントは無視する。
    """

    def __init__(self, db_pool, handler_fn):
        self.db_pool = db_pool
        self.handler_fn = handler_fn

    def handle(self, event: dict) -> bool:
        event_id = event["event_id"]

        with self.db_pool.connection() as conn:
            with conn.cursor() as cur:
                # 既に処理済みのイベントか確認
                cur.execute(
                    "SELECT 1 FROM processed_events WHERE event_id = %s",
                    (event_id,),
                )
                if cur.fetchone():
                    logger.info(f"Duplicate event {event_id}, skipping")
                    return True

                try:
                    # ビジネスロジック実行とイベント処理記録を1つのトランザクションで
                    self.handler_fn(event, cur)

                    cur.execute(
                        "INSERT INTO processed_events (event_id, processed_at) VALUES (%s, NOW())",
                        (event_id,),
                    )
                    conn.commit()
                    return True

                except Exception as e:
                    conn.rollback()
                    logger.error(f"Failed to process event {event_id}: {e}")
                    return False

-- Sagaステータスダッシュボードクエリ

-- 1. 時間帯別saga状態分布
SELECT
    date_trunc('hour', started_at) AS hour,
    status,
    COUNT(*) AS count,
    AVG(EXTRACT(EPOCH FROM (completed_at - started_at))) AS avg_duration_seconds
FROM saga_executions
WHERE started_at >= NOW() - INTERVAL '24 hours'
GROUP BY 1, 2
ORDER BY 1 DESC, 2;

-- 2. 補償失敗が発生したsaga（即時対応必要）
SELECT
    saga_id,
    started_at,
    error,
    jsonb_agg(
        jsonb_build_object(
            'step', step_name,
            'status', step_status,
            'error', step_error
        ) ORDER BY step_order
    ) AS step_details
FROM saga_executions e
JOIN saga_steps s ON e.saga_id = s.saga_id
WHERE e.status = 'FAILED'
  AND e.started_at >= NOW() - INTERVAL '7 days'
GROUP BY e.saga_id, e.started_at, e.error
ORDER BY e.started_at DESC;

-- 3. step別失敗率（ボトルネック特定）
SELECT
    step_name,
    COUNT(*) AS total_executions,
    SUM(CASE WHEN step_status = 'executed' THEN 1 ELSE 0 END) AS successes,
    SUM(CASE WHEN step_status != 'executed' THEN 1 ELSE 0 END) AS failures,
    ROUND(
        100.0 * SUM(CASE WHEN step_status != 'executed' THEN 1 ELSE 0 END) / COUNT(*),
        2
    ) AS failure_rate_pct
FROM saga_steps
WHERE created_at >= NOW() - INTERVAL '7 days'
GROUP BY step_name
ORDER BY failure_rate_pct DESC;
